Description
Details
General-Purpose Model
• Number of Channels ： 2,3,4,6,8,10,12
• Option of standard series or customized products.
Can be used with electrical slip rings
• Suitable for various media including hydraulic oil, water, compressed air, vacuum conditions, etc.
• High reliability and easy maintenance
Application
Various types of rotating machinery, automated equipment, and renewable energy.
Technical Specifications
| Number of Channels | 2 | 3 | 4 | 6 | 8 | 10 | 12 |
| Media | Various gases, coolant, chemical fluids, hydraulic oil, water, vacuum conditions | ||||||
| Bore Size | 1/8”, 1/4”, 3/8”, 1/2”, 3/4”, 1” (3.18 mm, 6.35 mm, 9.53 mm, 12.7 mm, 19.1 mm, 25.4 mm) | ||||||
| Connection | G Thread， NPT Thread, O-ring Flange Mount | ||||||
| Max Working Pressure | 50Mpa（ Consult an engineer for specific applications.） | ||||||
| Max Vacuum Rating | 30 HG | ||||||
| Max Speed | 350 RPM（ Consult an engineer for specific applications.） | ||||||
| Operating Temperature | -18° C to 105° C | ||||||
| Main Material | Carbon Steel | ||||||
| Slip ring | Optional | ||||||
| Installation Diagram |
|||||||
 |
|||||||
